Open single crankshaft precision punch

Release date: 2024-08-15 11:31:27 Visits: 195

● With high rigidity rack design, they are welded with theuse of high-quality steel plates, through relieving ofinternal stresses, so that stability and reliability of the whole machine in precision are enhanced.
● Consistent driving center and machine center toguarantee accurate and stable punching.
● Moulding-adjustment precision is as high as 0.01mm, safe, speedy,and reliable.

Performance feature

● In order to guarantee relative stationarity of machine operation, it isnecessary to balance two balancers.
● Through hard oxidation and grinding, such parts as bent axles, gear sets,and connecting rods possess higher combination property and tolerance.
● Adopt highly sensitive and reliable clutch/brake and internationallytop duplex magnetic valve, as well as overload protection devices, toguarantee precision and safety for operation and stop of press rams.
● Machine''''''''''''''''s structural design shall be reasonable, for the convenience ofrealizing automatic production, reducing cost, and improving efficiency.
● Possess advanced design concepts，low noise,low consumption, and energy saving.

Standard configuration

● Oil-pressure overload protection device
● HM slider adjusting device(≤ ET60)
● Electrodynamic-typeSlideradjusting device(≥ ET80)
● Frequency-conversion variable speed motor(speed controlled)
● Mechanical height indicator(≤ ET60)
● Digital height indicator(≥ET80)
● Slider and mold balancing device
● Electronic cam switch device
● Crankshaft angle indicator
● Electromagnetic-type counter
● Air source contact

● Second falling protector
● Air blowing device
● Mechanical quakeproof foot
● Miss inspection device
● Maintenance tools and tool cabinet
● Main motor inversion set
● Photoelectricity safety protection device
● Power socket
● Electrodynamic-type butter lubricating device(≥ET80)
● Touch screen(prejudge and preload)

Optional configuration

● Induction hardening of slider guide
● Precision grinding
● Vapor-pressure-typediebacker device
● Foot switch
● Quick exchange of die device
(die lifter, die clamper or die mover)

● Top of slider material device
● Feeder (air, machine and NC)
● Bump-cutter machine
● Mechanical arm
● Die lighting device
● Material frame
● Thin oil lubricating device
