Special machine for open double crankshaft battery shell
Release date: 2024-08-15 14:29:34 Visits: 130
● The battery shell drawing punch, the battery shell punch production line meets the needs of the rapid development of new energy vehicles and smart phone batteries. With the concept of "innovation", it has designed and developed a complete set of fully automatic multi-station stamping equipment, which has been successfully applied to the field of battery shell production.
Performance feature
● The precision of mold adjustment is as high as 0.01mm, safe, convenient and reliable.
● Such parts as crankshaft, gear set and connecting rod, after hard oxidation, mill and other fabrication processing, have extreme comprehensive mechanical performance and durable function.
● Adopt highly sensitive and reliable clutch/brake units and international top duplex magnetic valves and overload protection device, to guarantee the precision and safety of press slider revolving and stopping.
● Reasonable physical design is convenient to realize automatic production, reduce cost and increase efficiency.
Standard configuration
|
● Electronic crankshaft angle indicator ● Double-cylinder independent oil-pressure overload device ● Digital height indicator ● Imported electrodynamic butter lubricating device ● Electronic cam switch device ● Air blowing device ½” primary circuit ● Air source contact ½” secondary circuit ● Miss inspection device |
● Power socket ● Mechanical quakeproof foot ● Miss inspection device ● Maintenance tools and tool cabinet ● Main motor inversion set ● Photoelectricity safety protection device ● Second falling protector ● Converter ● Slider and mold balancing device |
Optional configuration
|
● Induction hardening of slider guide ● Precision grinding ● Vapor-pressure die backer device ● Cam top material device ● Foot switch |
● Safety dog and safety bolt ● Quick exchange of die device ● Automatic feeding device ● Flattener(bump-cutter machine) |
